TW18-08C Proximity Sensor (TAIWAN)

TW18-08C Proximity Sensor (TAIWAN) in Lahore Pakistan

Product Overview: Fotek TW18‑08C Inductive Proximity Sensor (Taiwan)

The Fotek TW18‑08C is part of the TW Series of two-wire inductive proximity sensors, designed for reliable metal detection in industrial automation.

Key Specs & Features:

• Type: Inductive proximity sensor, two-wire design

• Form Factor: M18 cylindrical housing (nickel‑plated brass) – threaded body, unshielded sensing face FotekFotek ExpressRadwell International

• Sensing Distance: 8 mm FotekFotek Express

• Output Configuration: Normally Open (N/O), two-wire setup FotekRadwell International

• Protection: Short-circuit and reverse-polarity protection included FotekFotek Express

• Ingress Protection: IP67 rated—dustproof and water-resistant FotekFotek Express

• Low Leakage Current: ≤ 0.8 mA FotekFotek Express

• Construction: Durable chrome-plated brass shell, unshielded sensor face, 2 m pre-wired cable included Radwell International+1Fotek ExpressFotek

How to Use

1. Mounting
   Thread the M18 body into the mounting bracket or surface and secure with the included nut.

2. Wiring Configuration

   • Use a two-wire connection: polarly insensitive (can work with either orientation)

   • When metallic target enters the 8 mm sensing range, the sensor switches its output state (circuit completes) FotekRadwell International.

3. Detection Operation
   On detection of a metal object, the sensor output changes state (typically drives load), and resumes idle when the target is removed.

4. Helpful Tips

   • Ensure targets are within 8 mm for optimal detection.

   • Avoid using non-ferrous metals—they reduce sensitivity.

   • Although polarity-protected, follow wiring guidelines to ensure consistent operation.

   • Regularly clean the sensing face to maintain detection reliability in dusty or oily environments.

Key Features (“Futures”)

• Robust Two-Wire Design: Simplifies wiring and reduces component count in control systems.

• Built-in Electrical Protection: Includes short-circuit and reverse-polarity protection for enhanced durability FotekFotek Express.

• Sturdy Construction & IP67 Rating: Withstands tough industrial conditions—safe against dust and water ingress FotekFotek Express.

• Low Leakage Current: Minimizes power loss and improves efficiency in two-wire installations FotekFotek Express.

• OEM Grade Reliability: Chrome-plated brass housing ensures longevity and corrosion resistance Radwell InternationalFotek.

• Replacement-Friendly: Available substitute models like TW18‑08C‑SUB under warranty add peace of mind for long-term availability Radwell International.

Suggested Website Copy Snippet

Product Title:
Fotek TW18‑08C Inductive Proximity Sensor (M18, 8 mm, Two‑Wire, N/O)

Short Description:
Reliable two-wire inductive sensor with 8 mm detection range, robust brass housing, built-in protection, and IP67 rating—perfect for demanding industrial applications.

Features Highlights:

• M18 brass body, unshielded sensing face

• 8 mm sensing distance, Normally Open output

• Two-wire design with short-circuit & reverse-polarity protection

• Low leakage current (≤0.8 mA), IP67-rated for harsh environments

• Durable, chrome-plated construction

Applications:
Ideal for metal detection in automation, conveyor systems, positioning, speed monitoring, packaging, and industrial control panels.

Usage Guidelines:
Mount securely, wire per operational polarity, ensure target within range, and maintain cleanliness for reliable sensing.
