Proximity Sensor PS17-5DN NPN

Proximity Sensor PS17-5DN NPN in Lahore Pakistan

Here’s a clean, polished website-ready overview for the Autonics PSN17‑5DN (Rectangular Inductive Proximity Sensor – NPN, 5 mm), complete with features, usage guidance, and benefits:

Product Overview

Autonics PSN17‑5DN is an industrial-grade inductive proximity sensor designed for reliable, non-contact detection of ferrous metal objects. With a compact 17 × 17 mm square housing and a 5 mm sensing range, it’s ideal for tight automation setups. It features a 3-wire NPN Normally Open output, LED indicator, and robust protection built-in.

Key Specifications

Features & Benefits

1. High-Speed Detection
   With a 700 Hz response rate, PSN17‑5DN excels in fast-moving automation systems.

2. Compact & Space-Efficient
   Its 17 × 17 mm form factor fits easily in tight assemblies.

3. Built-in Protection
   Featuring surge, reverse polarity, and overcurrent protection ensures reliability in harsh environments.

4. Visual Feedback via LED
   A red LED provides instant operation status visibility.

5. Robust IP67 Design
   Full dust and water resistance make it ideal for industrial settings.

6. Low Power Draw
   Efficient operation with max ≈ 10 mA current consumption.

7. Easily Replaceable
   Perfect substitute for mechanical limit or micro-switches—maintenance-free operation.

How to Use / Installation Steps

1. Mounting
   Secure the sensor using the bracket or housing. Its rectangular framing ensures front-facing detection alignment—30 mm depth as a guideline BaoAnJSCAutonics.

2. Wiring Connections

   • Brown → +12–24 VDC (10–30 VDC)

   • Blue → 0 V (Ground)

   • Black → NPN NO output to your control system

3. Power & Detection
   Power up the sensor. The red LED lights up when a metal target is within 5 mm.

4. Operation
   NPN NO output sinks to ground upon detection.

5. Testing & Validation
   Use a standard iron target (18 × 18 mm) at 5 mm distance. Adjust positioning to accommodate ±10 % hysteresis Dubai Sensor.

6. Environment & Maintenance
   Keep the sensor free of debris. Use proper cable strain relief and confirm IP67 sealing integrity.

Website Description (Concise Ready Copy)

Autonics PSN17‑5DN Rectangular Inductive Proximity Sensor – 5 mm, NPN NO, 3‑Wire (12–24 VDC)
A compact and high-speed inductive proximity sensor featuring a 5 mm detection range, 700 Hz response, rugged IP67 housing, and integrated surge, reverse-polarity, and overcurrent protection. Equipped with LED status indication and requiring just 10 mA for operation. Ideal for industrial automation, material handling, precise positioning, and efficient replacement of traditional limit micro-switches.

Example Use Applications

• Detect sheet or part presence on automatic feeder lines

• End-of-travel limit sensing on pneumatic/linear actuators

• Precise counting of metallic parts on conveyor belts

• Integrating with safety interlocks or visible/trip switches
