CDR-10X FOTEK M18 Photoelectric Switch Sensors in Lahore Pakistan

FOTEK CDR-10X M18 Photoelectric Switch Sensor

The FOTEK CDR-10X is a robust and high-performance M18 photoelectric switch sensor designed for detecting objects in industrial environments. With an M18 cylindrical design, this sensor is well-suited for integration into machinery, conveyors, assembly lines, and automation systems. It provides fast, reliable, and accurate object detection, making it a popular choice in motion detection, counting applications, and positioning systems.

Product Details:

Model: FOTEK CDR-10X M18 Photoelectric Switch Sensor
Sensing Type: Diffuse Reflective
Detection Range: 5mm to 10m (depending on the reflector used)
Output Type: NPN / PNP (Choose based on system compatibility)
Power Supply: 12V to 24V DC
Response Time: < 1 ms
Sensing Mode: Modulated Light
Beam Type: Red LED
Mounting Type: M18 threaded body (easy installation on mounting brackets)
Protection Rating: IP67 (dust-tight and waterproof)
Operating Temperature: -25°C to +55°C
Housing Material: Plastic housing with Stainless Steel option
Size: 18mm diameter x 50mm length
Weight: Approx. 35g
Wiring: Cable length 2 meters

Key Features:

1. Long Detection Range:
   The CDR-10X can detect objects from 5mm up to 10m. This wide sensing range allows it to be used for both small and large objects, making it ideal for a variety of automation systems.

2. Modulated Red LED Light:
   The sensor uses modulated red LED light to ensure reliable detection even in challenging environments with high ambient light. This reduces interference and enhances accuracy in object detection.

3. Compact M18 Design:
   With its M18 cylindrical body, the CDR-10X is compact yet durable, allowing for easy integration into tight spaces within machines, conveyors, and automated systems. The M18 mounting also ensures it fits most standard holders.

4. Fast Response Time:
   With a response time of <1 ms, the FOTEK CDR-10X is capable of high-speed detection, making it ideal for applications where fast object detection and sorting are crucial.

5. IP67 Protection:
   With an IP67 rating, the sensor is fully dust-tight and waterproof, making it suitable for use in harsh environments where exposure to dust, moisture, or splashing water is a concern.

6. Flexible Output Options:
   The CDR-10X comes with both NPN and PNP output configurations, allowing you to choose the correct option based on the needs of your control system. This ensures seamless integration with PLC or machine control units.

7. Energy Efficient:
   The sensor operates with a low power consumption of 12V to 24V DC, making it suitable for applications where energy efficiency is important.

How to Use the FOTEK CDR-10X M18 Photoelectric Switch Sensor:

1. Mounting the Sensor:

• Mounting:
  The CDR-10X features an M18 threaded body, allowing it to be easily mounted on a standard M18 holder or bracket. The M18 design ensures a secure and precise fit, which is ideal for stable positioning and consistent detection.

• Orientation:
  Ensure the sensor is aligned with the target object to optimize the detection range. The sensor should face the reflective surface if using the diffuse reflective mode. For best results, ensure the target object is within the detection range (typically 5mm to 10m, depending on the size and reflectivity of the object).

2. Wiring the Sensor:

• Power Supply:
  Connect the sensor to a DC power supply (12V to 24V). Connect the brown wire to the positive terminal and the blue wire to the negative terminal of the power supply.

• Output Wiring:
  The black wire is the output. Connect it to your PLC or controller system. Choose PNP or NPN output depending on your system's requirements.

  • PNP Output: This is a sourcing output—the sensor will output a positive voltage when the target is detected.

  • NPN Output: This is a sinking output—the sensor will output a ground signal when the target is detected.

3. Configuring the Sensor:

• Sensitivity Adjustment:
  The FOTEK CDR-10X typically comes with an adjustable sensitivity dial, allowing you to fine-tune the sensor's response to the reflective object. If you're working with different surface types or sizes, adjust the sensitivity to ensure accurate detection.

• Testing and Calibration:
  Once connected and powered, test the sensor by placing an object within the detection range. The sensor should trigger its output when the object is detected or reflected by the light beam.

• Mounting Angle:
  Ensure that the sensor is aligned at the proper angle to maximize the reflective detection performance, especially if detecting reflective targets at longer ranges.

4. Application Testing:

• Place various objects of different sizes and reflective properties within the sensor's detection range.

• Observe the response time and check that the sensor correctly triggers the output signal when objects pass through its detection area.

Applications of the FOTEK CDR-10X M18 Photoelectric Switch Sensor:

1. Conveyor Systems:
   Ideal for detecting the presence of objects on a conveyor belt, allowing for efficient sorting, counting, or positioning in automated material handling systems.

2. Object Detection in Assembly Lines:
   Used to detect the correct positioning or presence of components during an assembly process, ensuring high precision and quality control.

3. Packaging Automation:
   In packaging systems, the sensor can detect products moving along the line, triggering processes like packaging, counting, or quality inspection.

4. Robot Positioning:
   The CDR-10X is commonly used in robotic systems for part detection and positioning, helping robots locate objects or align themselves for precision tasks.

5. Sorting Systems:
   It can be used in sorting applications to detect and count objects before routing them to different locations based on predefined criteria.

6. Door and Gate Automation:
   Can be applied in automatic door or gate systems to detect when an object (person or vehicle) is approaching and trigger opening or closing mechanisms.

7. Industrial Equipment Monitoring:
   Suitable for monitoring the position of parts or tools in machines and ensuring correct operation and alignment during production.

Advantages of the FOTEK CDR-10X M18 Photoelectric Switch Sensor:

• Wide Detection Range: With a sensing range of 5mm to 10m, it can detect both small and large objects, offering versatility for different applications.

• Fast Response Time: The <1 ms response time makes it perfect for high-speed automation processes where timely detection is critical.

• Modulated Light Technology: Reduces the effect of ambient light interference, ensuring consistent performance in varying lighting conditions.

• IP67 Protection: Fully protected against dust and water, making it suitable for harsh industrial environments.

• Simple Installation: The M18 threaded body ensures easy and secure mounting, while the adjustable sensitivity allows fine-tuning for different detection needs.

• Reliable Performance: It offers long-lasting, reliable detection for continuous use in automated systems.

• Energy-Efficient: The sensor operates with low power consumption, making it ideal for energy-conscious applications.

Conclusion:

The FOTEK CDR-10X M18 Photoelectric Switch Sensor is a versatile, reliable, and cost-effective solution for industrial automation systems. With a wide detection range, fast response time, and IP67 rating, it is perfect for applications in conveyor systems, robotics, packaging, and assembly lines. Its compact M18 design, easy installation, and flexible output configurations make it an excellent choice for a wide range of industries, ensuring high performance and durability in challenging environments.
